Fodder Hammer Mill is the most ideal milling equipment of all kinds of wood pieces, straw, grass, stalk, tree branches, waste cardboard, bamboo, wood scrap, corn stalk, peanut shell, wheat stalk, wood fuel, cotton stalk, biomass shell,corn ,wheat and other grains etc.
This machine can cut and crush various crop straw, as well as feed grass such as corn straw, cotton straw, bean and orange, rice husk, peanut husk, sweet potato seedlings, grain straw, wheat straw, and various types of granular grains and miscellaneous grains. The machine has the characteristics of cutting grass and crushing as one, making it an ideal equipment for large, medium, and small farms and households to feed poultry such as chickens, ducks, pigs, cows, and sheep. This machine has low power, high output, simple structure, convenient operation, and can be operated by one person. The processing range is wide, and the raw materials are not limited in length.
working principle :
The machine uses a high-speed hammer to strike and crush the material entering the crushing chamber. Under the action of centrifugal force, the crushed powder particles are sent out of the machine through the sieve hole under the centrifugal pressure of the rotor and the suction force of the fan. The powder particles that do not pass the sieve hole repeat the above process until they can be sent out of the machine through the sieve hole.
|
Model
|
Motor power
|
capacity (kg/h)
|
Weight (kg)
|
Packing size(mm)
|
|
EWP158B
|
1.5kw
|
60-120kg/h
|
75/85kg
|
750*450*730mm
|
|
EWP198B
|
3kw
|
120-250kg/h
|
120/135kg
|
1000*750*1120mm
|
|
EWP420B-7.5
|
7.5kw
|
250-500kg/h
|
250/270kg
|
1200*1000*1220mm
|
|
EWP420B-11
|
11kw
|
250-700kg/h
|
300/320kg
|
1200*1000*1220mm
|
|
EWP500B-28B
|
11kw
|
400-800kg/h
|
470/500kg
|
1500*650*560mm
|
|
EWP500B-28B
|
15kw
|
400-1000kg/h
|
500/530kg
|
1100*930*980mm
|
|
EWP500B-40B
|
22kw
|
800-1000kg/h
|
710/755kg
|
1900*1100*1270mm
|
|
EWP500B-40B
|
30kw
|
800-1300kg/h
|
805/850kg
|
1900*1100*1270mm
|
|
EWP500B-60B
|
37kw
|
1000-1600kg/h
|
906/960kg
|
1900*1240*1270mm
|
|
EWP500B-60B
|
45kw
|
1000-2000kg/h
|
940/995kg
|
1900*1240*1270mm
|
|
Model
|
Matched Power
|
Capacity
|
Weight
|
Package size
|
|
EWF420-280A
|
15HP
|
250-500kg/h
|
370/390kg
|
1650*800*1120mm
|
|
EWF420-280A
|
22HP
|
250-700kg/h
|
390/410kg
|
1650*800*1120mm
|
|
EWF500-280A
|
22HP
|
400-1000kg/h
|
480/510kg
|
1700*800*980mm
|
|
EWF500-400A
|
55HP
|
800-1100kg/h
|
cyclone dust collector 125/145kg
Main machine310/330kg
Diesel engine560/590kg
|
2700*750*920mm
1150*800*1270mm
1500*1050*1320mm
|
wear parts :
